Multi-Point Handles Measurement Guide: Expert Tips for Accurate Fitting

At Trade Door Handles, we understand the importance of secure, functional, and visually appealing door hardware. Based in Kendal, Cumbria, and with over four decades of experience, we are proud to be one of North West England's largest suppliers of architectural ironmongery. One of the most common challenges homeowners and tradespeople face is selecting the right Multi-Point Door Handles for their doors.

Unlike standard handles, Multi-Point Door Handles are not universal and require precise measurements to ensure compatibility with the door’s locking mechanism. This comprehensive Multi-Point Handles Measurement Guide is designed to help you confidently measure and replace your handles while making the best choice from our wide range of options.

What Are Multi-Point Locking Handles?

Multi-point door handles are designed for multi-point locking systems, an advanced security mechanism commonly found on UPVC and composite doors and are becoming more popular in timber doors. These systems secure the door at multiple points, typically along the length of the frame, ensuring better protection against forced entry and improved sealing to enhance energy efficiency.

The Multi-Point Door Handle operates these locking points, engaging or disengaging them with a single action, making it an integral part of your door’s security and functionality.

Why Accurate Measurement Matters
When replacing a Multi-Point Door Handle, accurate measurements are crucial. A mismatch can lead to:

• Difficulty operating the locking system.
• Handles that don’t fit flush with the door.
• An unappealing finish with visible gaps or leftover marks.

To avoid these issues, careful measurement ensures your new handle fits seamlessly and operates as intended.

Common Types of Multi-Point Door Handles
At Trade Door Handles, we offer several types of Multi-Point Door Handles to accommodate a range of needs and lock mechanisms:

• Lever/Lever Door Handles: Feature two inline levers, making them the most popular choice for domestic UPVC doors. These handles are easy to use and available in various traditional and modern styles.
• Lever/Movable Pad (Inline): Ideal for split spindle mechanisms, allowing independent operation of the lever and pad.
• Lever/Movable Pad (Offset): Designed for double spindle locks, enabling separate movement of the levers on either side of the door.
• Lever/Fixed Pad: Suitable for keywind locks or applications without external access.
• Handle with Snib: Includes a snib latch feature to hold the lock in place, providing added convenience.

While Lever/Lever handles are the most common for domestic properties, we can supply all these options through our trusted suppliers, ensuring a solution for every need.

Taking accurate measurements is critical when replacing your Multi-Point Door Handles. Use a reliable tape measure and follow these steps outlined in our Multi-Point Handles Measurement Guide:

1. Backplate Size (A): Measure the length and width of the backplate. Ensure the new handle’s backplate is the same size or larger to cover any marks or indentations left by the old handle.
2. Screw Centers (B): Measure the distance between the two screw holes. Most Multi-Point Door Handles have fixings located at the top and bottom of the handle, but some models include an additional fixing below the lever.
3. Spindle to Top Screw (C): Measure the distance from the spindle centre to the top screw fixing.
4. Spindle to Euro Hole Center (D): Measure the distance between the spindle centre and the top edge of the euro hole cut-out. Typical measurements include 70mm and 92mm, with 92mm being the most widely used.
5. Euro Hole Bottom to Bottom Screw (E): Record the distance from the bottom of the euro cut-out to the bottom screw hole.

Ensure all measurements are taken in millimetres for consistency and accuracy.

Avoid Common Mistakes

• Use a metric tape measure to ensure precise readings.
• Don’t skip measuring the backplate size—it affects aesthetics and fit.
• Always double-check your screw centre measurements to avoid alignment issues.

Replacing a Multi-Point Door Handle is a straightforward process if you have the right tools and follow these steps:

Step 1: Remove the Old Handle
Use a screwdriver to remove the screws holding the handle in place. These screws are usually located on the interior side of the door. Once removed, gently pull the handle away from the door.

Step 2: Double-check the Measurements
Before installing the new handle, compare its dimensions to your recorded measurements. This ensures a proper fit.

Step 3: Drill New Holes (If Necessary)
If the new handle’s screw or spindle positions differ, you may need to drill new holes. Carefully check the placement of the door lock mechanism to avoid damaging it while drilling.

Step 4: Install the New Handle
Slide the spindle through the door and align the handle with the screw holes. Secure the handle in place using the screws provided.

Step 5: Test the Handle
Operate the handle to confirm it moves smoothly and engages the locking mechanism correctly.

At Trade Door Handles, on our website, we have over 100 styles of Multi-Point Door Handles sourced from leading brands like Carlisle Brass, From The Anvil, and Heritage Brass. Our selection includes various finishes and designs to match your door’s aesthetic while ensuring compatibility with your lock mechanism.

For those seeking readily available options, we offer quick delivery for off-the-shelf products from trusted brands. These handles provide various styles and finishes, catering to modern and traditional tastes while ensuring reliable performance and compatibility.

For customers with more specific requirements, we also provide a bespoke service in partnership with premium British manufacturers such as Kirkpatrick, Frank Allart, and Croft. These brands specialize in crafting custom-made handles that deliver exceptional quality and craftsmanship. While this service offers unique solutions, it requires a longer lead time—typically several weeks—and is a premium option. Nevertheless, this bespoke service is ideal for restoring older systems, replacing hard-to-find handles, or achieving a distinctive look that standard products cannot provide.

Whether you’re looking for a quick replacement or a tailored solution, our team is here to help you make the best choice. Don't hesitate to reach out if you’re unsure about your measurements or need professional advice. At Trade Door Handles, we offer solutions that meet every need, ensuring your Multi-Point Door Handles are functional and visually stunning.

To ensure longevity and optimal performance:

• Clean handles regularly with a damp cloth to remove dirt and grime.
• Lubricate moving parts occasionally to keep them functioning smoothly.
• Check for signs of wear, such as loose screws or sticking levers, and address issues promptly.

With over 1,000 door handles on display and partnerships with top UK manufacturers, Trade Door Handles is your go-to destination for all your architectural ironmongery needs. Whether you’re replacing a single handle or undertaking a large-scale project, we provide unparalleled variety, quality, and expertise.

Replacing a Multi-Point Door Handle doesn’t have to be complicated. By following this Multi-Point Handles Measurement Guide and ensuring accurate measurements, you can find the perfect handle for your door. At Trade Door Handles, we offer the largest selection of handles in the North West, backed by decades of experience and a commitment to customer satisfaction. Visit our showroom or contact us for personalized advice and solutions.
